Before we dive into this wonderful conversation, would you be able to define what a printed circuit board is, please, for our audience?

Sure.

A printed circuit board, or you often will hear it referred to as a PCB.

is the physical board inside an electronic product that connects and carries all the components that make the electronic works.

So it's where All the silicon components sit.

So the real time is where everything's going.

So then I'll ask you this then, what becomes the brain? What becomes that digital thread that connects all of this, or if you want to use the AI term, the MD file?

The thing that's very unique in electronic design and PCB design is it's one of the few tools that sits that spans and i'd like to think about this as a bridge and on one side of the bridge is the digital world where engineers are designing their products and on the other side of the bridge is the physical world sourcing manufacturing the whole physical end of the implementation and The PCB design flow is in one spot where those two things come together and bridge those two worlds.
